Drinking Water Pilot

Description

Drinking Water Pilot

Teaching Objectives of

Drinking Water Pilot

• Analysis with industrial sensors of chlorine, turbidity at the output of the decanter or filters, pH measurement.

Technical specifications

• A turbidity sensor and transmitter.
• Four solenoid valves.
• Three tanks.
• Three peristaltic pumps.
• A stirrer.
• Decanting tank adaptor for installing the turbidity sensor.
• Adaptor at the base of the filtration column for the turbidity sensor.
• Tank for treated product.
• Alarms with two levels on high and low alarms.
• Control panel with all controls.
• Alarms with two levels on high and low alarms.

Dimensions

• 4000 x 800 x 2000 mm

Essential requirements

• Solution of CuSO4 10-3 M with lime (50 mg/l),
• Sand bed : H = 60 cm – Int diam = 10 cm Granule size : 0.8 < d < 1 mm.
• Flocculation – Decanting of CuSO4 with lime. Starch – FeCl3.
• Power supply : 220 V / single phase / 50 Hz
