Thermal Conductivity Unit

Description

Specification:-

• Measuring principle  transient heat flow (needle probe method)
• Measuring range  0.1 to 10 W/mK *
• Accuracy  ± 2 % *
• Reproducibility  ± 1.5 %
• Heater current precision  ± 0.01 %
• Duration of 1 measurement  60 / 80 / 240 s *
• Automatic repetitions  up to 99 measurements per series (unattended)
• Sample size  no upper limit, minimum size probe dependent
  Sample shape  any
• Operating temperature  0 to 45°C
• Sample temperature  – 25 tos 50°C / – 25 to 70°C / -25 to 125°C *
• Power supply  220/240 V AC (50 Hz);
• Power consumption  40 W
• Dimensions (W x H x D)  471 x 160 x 391 mm
